Automatic Wire 3D Bend Machine 0.75 to 35mm2 Wire Cable Cutting Stripping Bending Machine Wire Stripping Bending Machine

Name: Automatic Wire 3D Bend Machine 0.75 to 35mm2 Wire Cable Cutting Stripping Bending Machine Wire Stripping Bending Machine
Brand: WideWorlddeal
Price: 443.00 USD
Availability: InStock

Anzahl

$443.00

~~$443.00~~ $443.00

Sale Ausverkauft

Versand wird beim Checkout berechnet

Auf Lager

Product Pictures

Products Description

1. No mechanical contact output control, long service life of the entire machine. 2. Adopting a multi level functional structure: manual, single step, semi-automatic, and fully automatic functions, which can be freely selected according to needs. 3. The peeling mouth has both full and partial peeling functions; Suitable for various spacing cable arrangement. 4. The inlet speed and air blowing can be adjusted, and there are four selection knobs set. 5. The incoming line is driven by a stepper motor to ensure the length and accuracy of the tangent. 6. The counting LED display and the pull-out switch set the number of stripped wires and the length of the tangent, making the operation simple and convenient. 7. It has a branching function, which doubles the efficiency. 8. Equipped with a dedicated cable laying mechanism. The QP-88 computer cable stripping machine adopts imported pneumatic components and stepper motor drives from Japan, and uses high-performance and highly reliable programmable controllers. The whole machine works reliably and has stable performance

Specification

Name	Fully automatic computer cable laying and branching machine
Model	STR-220
Function	Integrated wiring cutting, branching, and peeling
Power Supply	110V/20V 50/60 Hz
Power	120 to 220 watts
Weight	45KG
External dimensions	650450450MM
Cut length	0.1 -9999.9MM
Stripping Length	Head peeling 0.1-50mm, tail peeling 0.1-30mm
Line length	Adjustable
Cut off differential	0.02 * liter millimeters
Splitting mode	Pneumatic branch line suitable for wire diameter 2PIN-24PIN
Applicable wire diameter	AWG # 16-AWG # 32 (specific line of sight material depends)
Productivity	2000-8000 pieces
Driving method	Integrated pneumatic and electrical drive
